iPhone 7 dead from VDD_MAIN short

iPhone 7 PP_VDD_MAIN short. Everything in red is part of this line. It is easy to see where the problem lies when looking at this board! These capacitors have broken and turned into a direct wire to ground. This sends all the voltage directly to ground and prevents the phone from turning on. Once replaced, this phone turns on and pictures and data are saved!
